With the RFID card tested with basic software, it's now time to turn and look at what to do with the actual RFID cards themselves. What to do with them as plain white with a sticker on them doesn't look good.
Designing the cards
What to put on the cards and what should they look like was a question to ponder over. Then after a prolonged case of procrastination, an idea was formed & Illustrator was opened and designing started.
The other thing that came together was the name of the new machine. It was in keeping with the original PPC range (the 512 & 640) that was named after how many kilobytes of RAM the machine had. In this case it's how many Megabytes!
The Front
This has a nod to the original design & colour scheme of the, original, PPC640. It will probably have a slight redesign when the "empty area" at the bottom will be filled with something appropriate
The Back
IF you have two sides, you might as well use them! This side is just a take on "if you find this card" information that is on normal ID cards
